C2306917 Pressure equalisation element M6x0.75

C2306917

Pressure equalisation element M6x0.75

Pressure equalisation elements with highly improved air exchange for protecting sensitive electronics. Changing atmospheric conditions and a sudden decrease in temperature can cause underpressure inside protective housings of technical equipment. Water and dirt can penetrate the gaskets damaging electronics in the process. The patented IQ TEX® technology is the ideal solution for urgent pressure balancing in large control cabinets and all protective housings. At the same time the innovative construction of IQ TEX® protects against foreign material and dirt. If required, it is absolutely watertight up to a pressure of 6 bar.
Airflow: 6.5 L/min - 0.25 bar; 16.5 L/min - 1 bar.
Water entry pressure > 6 bar.
Temperature range -40°C/+110°C.
Sealing material: BASF Luquafleece + PA6 mesh (insert molding).

Supply

1 pressure equalisation element, 1 seal washer, 1 nut

  • To be used for
C0080801 Case shell 80, with groove

C0080801

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C0080801

Case shell 80, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
80x80x20mm
C0080802 Case shell 80, with groove

C0080802

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C0080802

Case shell 80, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
80x80x20mm
C0081201 Case shell 80, with groove

C0081201

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C0081201

Case shell 80, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
120x80x20mm
C0081202 Case shell 80, with groove

C0081202

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C0081202

Case shell 80, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
120x80x20mm
C0081601 Case shell 80, with groove

C0081601

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C0081601

Case shell 80, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
160x80x20mm
C0081602 Case shell 80, with groove

C0081602

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C0081602

Case shell 80, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
160x80x20mm
C0082401 Case shell 80, with groove

C0082401

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C0082401

Case shell 80, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x80x20mm
C0082402 Case shell 80, with groove

C0082402

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C0082402

Case shell 80, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x80x20mm
C0121201 Case shell 120, with tongue

C0121201

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C0121201

Case shell 120, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
120x120x30mm
C0121202 Case shell 120, with tongue

C0121202

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C0121202

Case shell 120, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
120x120x30mm
C0122001 Case shell 120, with tongue

C0122001

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C0122001

Case shell 120, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
200x120x30mm
C0122002 Case shell 120, with tongue

C0122002

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C0122002

Case shell 120, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
200x120x30mm
C0122401 Case shell 120, with tongue

C0122401

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C0122401

Case shell 120, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x120x30mm
C0122402 Case shell 120, with tongue

C0122402

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C0122402

Case shell 120, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x120x30mm
C0161601 Case shell 160, with tongue

C0161601

Case shell 160, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C0161601

Case shell 160, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
160x160x30mm
C0161602 Case shell 160, with tongue

C0161602

Case shell 160, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C0161602

Case shell 160, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
160x160x30mm
C0162401 Case shell 160, with tongue

C0162401

Case shell 160, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C0162401

Case shell 160, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x160x30mm
C0162402 Case shell 160, with tongue

C0162402

Case shell 160, with tongue Case shell with thread and fixing towers as separate part.´Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C0162402

Case shell 160, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x160x30mm
C1080801 Case shell 80, with tongue

C1080801

Case shell 80, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C1080801

Case shell 80, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
80x80x40mm
C1080802 Case shell 80, with tongue

C1080802

Case shell 80, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C1080802

Case shell 80, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
80x80x40mm
C1081201 Case shell 80, with tongue

C1081201

Case shell 80, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C1081201

Case shell 80, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
120x80x40mm
C1081202 Case shell 80, with tongue

C1081202

Case shell 80, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C1081202

Case shell 80, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
120x80x40mm
C1081601 Case shell 80, with tongue

C1081601

Case shell 80, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C1081601

Case shell 80, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
160x80x40mm
C1081602 Case shell 80, with tongue

C1081602

Case shell 80, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C1081602

Case shell 80, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
160x80x40mm
C1082401 Case shell 80, with tongue

C1082401

Case shell 80, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C1082401

Case shell 80, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x80x40mm
C1082402 Case shell 80, with tongue

C1082402

Case shell 80, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C1082402

Case shell 80, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x80x40mm
C1121201 Case shell 120, with groove

C1121201

Case shell 120, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C1121201

Case shell 120, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
120x120x30mm
C1121202 Case shell 120, with groove

C1121202

Case shell 120, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C1121202

Case shell 120, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
120x120x30mm
C1122001 Case shell 120, with groove

C1122001

Case shell 120, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C1122001

Case shell 120, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
200x120x30mm
C1122002 Case shell 120, with groove

C1122002

Case shell 120, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C1122002

Case shell 120, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
200x120x30mm
C1122401 Case shell 120, with groove

C1122401

Case shell 120, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C1122401

Case shell 120, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x120x30mm
C1122402 Case shell 120, with groove

C1122402

Case shell 120, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C1122402

Case shell 120, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x120x30mm
C1161601 Case shell 160, with groove

C1161601

Case shell 160, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C1161601

Case shell 160, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
160x160x30mm
C1161602 Case shell 160, with groove

C1161602

Case shell 160, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C1161602

Case shell 160, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
160x160x30mm
C1162401 Case shell 160, with groove

C1162401

Case shell 160, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C1162401

Case shell 160, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x160x30mm
C1162402 Case shell 160, with groove

C1162402

Case shell 160, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C1162402

Case shell 160, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x160x30mm
C1203001 Case shell 200, with tongue

C1203001

Case shell 200, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C1203001

Case shell 200, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
300x200x40mm
C1243601 Case shell 240, with tongue

C1243601

Case shell 240, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C1243601

Case shell 240, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
360x240x40mm
C2008081 ROBUST-BOX WIDTH 80, Vers. I

C2008081

ROBUST-BOX WIDTH 80, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealeing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2008081

ROBUST-BOX WIDTH 80, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
80x80x60mm
IP 66
C2008082 ROBUST-BOX WIDTH 80, Vers. II

C2008082

ROBUST-BOX WIDTH 80, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2008082

ROBUST-BOX WIDTH 80, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
80x80x60mm
IP 66
C2008121 ROBUST-BOX WIDTH 80, Vers. I

C2008121

ROBUST-BOX WIDTH 80, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2008121

ROBUST-BOX WIDTH 80, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
120x80x60mm
IP 66
C2008122 ROBUST-BOX WIDTH 80, Vers. II

C2008122

ROBUST-BOX WIDTH 80, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2008122

ROBUST-BOX WIDTH 80, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
120x80x60mm
IP 66
C2008161 ROBUST-BOX WIDTH 80, Vers. I

C2008161

ROBUST-BOX WIDTH 80, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2008161

ROBUST-BOX WIDTH 80, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
160x80x60mm
IP 66
C2008162 ROBUST-BOX WIDTH 80, Vers. II

C2008162

ROBUST-BOX WIDTH 80, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2008162

ROBUST-BOX WIDTH 80, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
160x80x60mm
IP 66
C2008241 ROBUST-BOX WIDTH 80, Vers. I

C2008241

ROBUST-BOX WIDTH 80, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2008241

ROBUST-BOX WIDTH 80, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x80x60mm
IP 66
C2008242 ROBUST-BOX WIDTH 80, Vers. II

C2008242

ROBUST-BOX WIDTH 80, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2008242

ROBUST-BOX WIDTH 80, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x80x60mm
IP 66
C2012121 ROBUST-BOX WIDTH 120, Vers. I

C2012121

ROBUST-BOX WIDTH 120, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2012121

ROBUST-BOX WIDTH 120, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
120x120x60mm
IP 66
C2012122 ROBUST-BOX WIDTH 120, Vers. II

C2012122

ROBUST-BOX WIDTH 120, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2012122

ROBUST-BOX WIDTH 120, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
120x120x60mm
IP 66
C2012201 ROBUST-BOX WIDTH 120, Vers. I

C2012201

ROBUST-BOX WIDTH 120, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2012201

ROBUST-BOX WIDTH 120, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
200x120x60mm
IP 66
C2012202 ROBUST-BOX WIDTH 120, Vers. II

C2012202

ROBUST-BOX WIDTH 120, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2012202

ROBUST-BOX WIDTH 120, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
200x120x60mm
IP 66
C2012241 ROBUST-BOX WIDTH 120, Vers. I

C2012241

ROBUST-BOX WIDTH 120, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2012241

ROBUST-BOX WIDTH 120, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x120x60mm
IP 66
C2012242 ROBUST-BOX WIDTH 120, Vers, II

C2012242

ROBUST-BOX WIDTH 120, Vers, II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2012242

ROBUST-BOX WIDTH 120, Vers, II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x120x60mm
IP 66
C2016161 ROBUST-BOX WIDTH 160, Vers. I

C2016161

ROBUST-BOX WIDTH 160, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2016161

ROBUST-BOX WIDTH 160, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
160x160x60mm
IP 66
C2016162 ROBUST-BOX WIDTH 160, Vers. II

C2016162

ROBUST-BOX WIDTH 160, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2016162

ROBUST-BOX WIDTH 160, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
160x160x60mm
IP 66
C2016241 ROBUST-BOX WIDTH 160, Vers. I

C2016241

ROBUST-BOX WIDTH 160, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2016241

ROBUST-BOX WIDTH 160, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x160x60mm
IP 66
C2016242 ROBUST-BOX WIDTH 160, Vers. II

C2016242

ROBUST-BOX WIDTH 160, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2016242

ROBUST-BOX WIDTH 160, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x160x60mm
IP 66
C2080801 Case shell 80, with groove

C2080801

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C2080801

Case shell 80, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
80x80x40mm
C2080802 Case shell 80, with groove

C2080802

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C2080802

Case shell 80, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
80x80x40mm
C2081201 Case shell 80, with groove

C2081201

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C2081201

Case shell 80, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
120x80x40mm
C2081202 Case shell 80, with groove

C2081202

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C2081202

Case shell 80, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
120x80x40mm
C2081601 Case shell 80, with groove

C2081601

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C2081601

Case shell 80, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
160x80x40mm
C2081602 Case shell 80, with groove

C2081602

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C2081602

Case shell 80, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
160x80x40mm
C2082401 Case shell 80, with groove

C2082401

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C2082401

Case shell 80, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x80x40mm
C2082402 Case shell 80, with groove

C2082402

Case shell 80, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C2082402

Case shell 80, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x80x40mm
C2108081 ROBUST-BOX WIDTH 80, Vers. I

C2108081

ROBUST-BOX WIDTH 80, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and botttom, assembly kit

Close

C2108081

ROBUST-BOX WIDTH 80, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
80x80x80mm
IP 66
C2108082 ROBUST-BOX WIDTH 80, Vers. II

C2108082

ROBUST-BOX WIDTH 80, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2108082

ROBUST-BOX WIDTH 80, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
80x80x80mm
IP 66
C2108121 ROBUST-BOX WIDTH 80, Vers. I

C2108121

ROBUST-BOX WIDTH 80, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2108121

ROBUST-BOX WIDTH 80, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
120x80x80mm
IP 66
C2108122 ROBUST-BOX WIDTH 80, Vers. II

C2108122

ROBUST-BOX WIDTH 80, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2108122

ROBUST-BOX WIDTH 80, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
120x80x80mm
IP 66
C2108161 ROBUST-BOX WIDTH 80, Vers. I

C2108161

ROBUST-BOX WIDTH 80, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2108161

ROBUST-BOX WIDTH 80, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
160x80x80mm
IP 66
C2108162 ROBUST-BOX WIDTH 80, Vers. II

C2108162

ROBUST-BOX WIDTH 80, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2108162

ROBUST-BOX WIDTH 80, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
160x80x80mm
IP 66
C2108241 ROBUST-BOX WIDTH 80, Vers. I

C2108241

ROBUST-BOX WIDTH 80, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2108241

ROBUST-BOX WIDTH 80, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x80x80mm
IP 66
C2108242 ROBUST-BOX WIDTH 80, Vers. II

C2108242

ROBUST-BOX WIDTH 80, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2108242

ROBUST-BOX WIDTH 80, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x80x80mm
IP 66
C2112121 ROBUST-BOX WIDTH 120, Vers. I

C2112121

ROBUST-BOX WIDTH 120, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2112121

ROBUST-BOX WIDTH 120, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
120x120x90mm
IP 66
C2112122 ROBUST-BOX WIDTH 120, Vers. II

C2112122

ROBUST-BOX WIDTH 120, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2112122

ROBUST-BOX WIDTH 120, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
120x120x90mm
IP 66
C2112201 ROBUST-BOX WIDTH 120, Vers. I

C2112201

ROBUST-BOX WIDTH 120, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2112201

ROBUST-BOX WIDTH 120, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
200x120x90mm
IP 66
C2112202 ROBUST-BOX WIDTH 120, Vers. II

C2112202

ROBUST-BOX WIDTH 120, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2112202

ROBUST-BOX WIDTH 120, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
200x120x90mm
IP 66
C2112241 ROBUST-BOX WIDTH 120, Vers. I

C2112241

ROBUST-BOX WIDTH 120, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2112241

ROBUST-BOX WIDTH 120, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x120x90mm
IP 66
C2112242 ROBUST-BOX WIDTH 120, Vers. II

C2112242

ROBUST-BOX WIDTH 120, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2112242

ROBUST-BOX WIDTH 120, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x120x90mm
IP 66
C2116161 ROBUST-BOX WIDTH 160, Vers. I

C2116161

ROBUST-BOX WIDTH 160, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2116161

ROBUST-BOX WIDTH 160, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
160x160x90mm
IP 66
C2116162 ROBUST-BOX WIDTH 160, Vers. II

C2116162

ROBUST-BOX WIDTH 160, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2116162

ROBUST-BOX WIDTH 160, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
160x160x90mm
IP 66
C2116241 ROBUST-BOX WIDTH 160, Vers. I

C2116241

ROBUST-BOX WIDTH 160, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2116241

ROBUST-BOX WIDTH 160, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x160x90mm
IP 66
C2116242 ROBUST-BOX WIDTH 160, Vers. II

C2116242

ROBUST-BOX WIDTH 160, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2116242

ROBUST-BOX WIDTH 160, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x160x90mm
IP 66
C2120301 ROBUST-BOX WIDTH 200, Vers. I

C2120301

ROBUST-BOX WIDTH 200, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2120301

ROBUST-BOX WIDTH 200, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
300x200x80mm
IP 66
C2121201 Case shell 120, with tongue

C2121201

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C2121201

Case shell 120, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
120x120x60mm
C2121202 Case shell 120, with tongue

C2121202

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C2121202

Case shell 120, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
120x120x60mm
C2122001 Case shell 120, with tongue

C2122001

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C2122001

Case shell 120, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
200x120x60mm
C2122002 Case shell 120, with tongue

C2122002

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C2122002

Case shell 120, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
200x120x60mm
C2122401 Case shell 120, with tongue

C2122401

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C2122401

Case shell 120, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x120x60mm
C2122402 Case shell 120, with tongue

C2122402

Case shell 120, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C2122402

Case shell 120, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x120x60mm
C2124361 ROBUST-BOX WIDTH 240, Vers. I

C2124361

ROBUST-BOX WIDTH 240, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2124361

ROBUST-BOX WIDTH 240, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
360x240x80mm
IP 66
C2161601 Case shell 160, with tongue

C2161601

Case shell 160, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C2161601

Case shell 160, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
160x160x60mm
C2161602 Case shell 160, with tongue

C2161602

Case shell 160, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C2161602

Case shell 160, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
160x160x60mm
C2162401 Case shell 160, with tongue

C2162401

Case shell 160, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C2162401

Case shell 160, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x160x60mm
C2162402 Case shell 160, with tongue

C2162402

Case shell 160, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C2162402

Case shell 160, with tongue
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x160x60mm
C2203001 Case shell 200, with groove

C2203001

Case shell 200, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C2203001

Case shell 200, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
300x200x40mm
C2243601 Case shell 240, with groove

C2243601

Case shell 240, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C2243601

Case shell 240, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
360x240x40mm
C2416241 ROBUST-BOX WIDTH 160, Vers. I

C2416241

ROBUST-BOX WIDTH 160, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2416241

ROBUST-BOX WIDTH 160, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x160x120mm
IP 66
C2416242 ROBUST-BOX WIDTH 160, Vers. II

C2416242

ROBUST-BOX WIDTH 160, Vers. II Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2416242

ROBUST-BOX WIDTH 160, Vers. II
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x160x120mm
IP 66
C2420301 ROBUST-BOX WIDTH 200, Vers. I

C2420301

ROBUST-BOX WIDTH 200, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2420301

ROBUST-BOX WIDTH 200, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
300x200x120mm
IP 66
C2424361 ROBUST-BOX WIDTH 240, Vers. I

C2424361

ROBUST-BOX WIDTH 240, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2424361

ROBUST-BOX WIDTH 240, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
360x240x120mm
IP 66
C2520301 ROBUST-BOX WIDTH 200, Vers. I

C2520301

ROBUST-BOX WIDTH 200, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Lid fixing outside of sealed area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2520301

ROBUST-BOX WIDTH 200, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
300x200x160mm
IP 66
C2524361 ROBUST-BOX WIDTH 240, Vers. I

C2524361

ROBUST-BOX WIDTH 240, Vers. I Robust plastic enclosure, ideal for electrical and electronic applications. Case shells either usable as top or base part. Each case part contains threads and fixing towers. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for use of membrane keyboards.

Supply 2 case shells with sealing, cover strips top and bottom, assembly kit

Close

C2524361

ROBUST-BOX WIDTH 240, Vers. I
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
360x240x160mm
IP 66
C3006061 SNAPTEC 60 x 60

C3006061

SNAPTEC 60 x 60 Top and base parts are fitted together using a unique snap-in machanism. Fixing towers in top and base part. Recessed area for membrane keyboards. Simple, invisible wall-mounting in pre-moulded shafts within the base part.

Supply 1 top and base part with sealing, cover for the locking openings, dismantling key

Close

C3006061

SNAPTEC 60 x 60
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
60x60x40mm
IP 65
C3006101 SNAPTEC 60 x 100

C3006101

SNAPTEC 60 x 100 Top and base parts are fitted together using a unique snap-in machanism. Fixing towers in top and base part. Recessed area for membrane keyboards. Simple, invisible wall-mounting in pre-moulded shafts within the base part.

Supply 1 top and base part with sealing, covers for the locking openings, dismantling key

Close

C3006101

SNAPTEC 60 x 100
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
60x100x40mm
IP 65
C3010101 SNAPTEC 100 x 100

C3010101

SNAPTEC 100 x 100 Top and base parts are fitted together using a unique snap-in machanism. Fixing towers in top and base part. Recessed area for membrane keyboards. Simple, invisible wall-mounting in pre-moulded shafts within the base part.

Supply 1 top and base part with sealing, covers for the locking openings, dismantling key

Close

C3010101

SNAPTEC 100 x 100
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
100x100x80mm
IP 65
C3162401 Case shell 160, with groove

C3162401

Case shell 160, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C3162401

Case shell 160, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
240x160x60mm
C3162402 Case shell 160, with groove

C3162402

Case shell 160, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C3162402

Case shell 160, with groove
product added to your list
PC (UL 94 HB)
light grey RAL 7035
240x160x60mm
C4203001 Case shell 200, with tongue

C4203001

Case shell 200, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C4203001

Case shell 200, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
300x200x80mm
C4243601 Case shell 240, with tongue

C4243601

Case shell 240, with tongue Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with tongue

Close

C4243601

Case shell 240, with tongue
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
360x240x80mm
C5203001 Case shell 200, with groove

C5203001

Case shell 200, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C5203001

Case shell 200, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
300x200x80mm
C5243601 Case shell 240, with groove

C5243601

Case shell 240, with groove Case shell with thread and fixing towers as separate part. Alternative use either as top or bottom part. Screw fixing outside of the sealing area. Recess of approx. 0.8 mm for the use of membrane keyboards. Each 1 part with tongue and 1 part with groove needed for 1 case.

Supply 1 case shell with groove

Close

C5243601

Case shell 240, with groove
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
360x240x80mm
C6009121 SMART-BOX WIDTH 90

C6009121

SMART-BOX WIDTH 90 Four-part plastic enclosure, ideal for design orientated electrical and electronic applications. The sealing is already prefitted in the top. Screw fixing outside of the sealing area. Resessed operating area to protect the membrane keyboard. Fastening pillars for PCBs and DIN-rails.

Supply 1 base and top part with sealing, 2 trims, 1 assembly kit incl. cover retention

Close

C6009121

SMART-BOX WIDTH 90
product added to your list
ASA+PC-FR (UL 94 V-0)
light grey RAL 7035
120x90x50mm
IP 66
C6009161 SMART-BOX WIDTH 90

C6009161

SMART-BOX WIDTH 90 Four-part plastic enclosure, ideal for design orientated electrical and electronic applications. The sealing is already prefitted in the top. Screw fixing outside of the sealing area. Resessed operating area to protect the membrane keyboard. Fastening pillars for PCBs and DIN-rails.

Supply 1 base and top part with sealing, 2 trims, 1 assembly kit incl. cover retention

Close

C6009161

SMART-BOX WIDTH 90
product added to your list
ASA+PC-FR (UL 94 V-0)
light grey RAL 7035
160x90x50mm
IP 66
C6011141 SMART-BOX WIDTH 110

C6011141

SMART-BOX WIDTH 110 Four-part plastic enclosure, ideal for design orientated electrical and electronic applications. The sealing is already prefitted in the top. Screw fixing outside of the sealing area. Resessed operating area to protect the membrane keyboard. Fastening pillars for PCBs and DIN-rails.

Supply 1 base and top part with sealing, 2 trims, 1 assembly kit incl. cover retention

Close

C6011141

SMART-BOX WIDTH 110
product added to your list
ASA+PC-FR (UL 94 V-0)
light grey RAL 7035
140x110x60mm
IP 66
C6011201 SMART-BOX WIDTH 110

C6011201

SMART-BOX WIDTH 110 Four-part plastic enclosure, ideal for design orientated electrical and electronic applications. The sealing is already prefitted in the top. Screw fixing outside of the sealing area. Resessed operating area to protect the membrane keyboard. Fastening pillars for PCBs and DIN-rails.

Supply 1 base and top part with sealing, 2 trims, 1 assembly kit incl. cover retention

Close

C6011201

SMART-BOX WIDTH 110
product added to your list
ASA+PC-FR (UL 94 V-0)
light grey RAL 7035
200x110x60mm
IP 66
C6013161 SMART-BOX WIDTH 130

C6013161

SMART-BOX WIDTH 130 Four-part plastic enclosure, ideal for design orientated electrical and electronic applications. The sealing is already prefitted in the top. Screw fixing outside of the sealing area. Resessed operating area to protect the membrane keyboard. Fastening pillars for PCBs and DIN-rails.

Supply 1 base and top part with sealing, 2 trims, 1 assembly kit incl. cover retention

Close

C6013161

SMART-BOX WIDTH 130
product added to your list
ASA+PC-FR (UL 94 V-0)
light grey RAL 7035
160x130x60mm
IP 66
C6013221 SMART-BOX WIDTH 130

C6013221

SMART-BOX WIDTH 130 Four-part plastic enclosure, ideal for design orientated electrical and electronic applications. The sealing is already prefitted in the top. Screw fixing outside of the sealing area. Resessed operating area to protect the membrane keyboard. Fastening pillars for PCBs and DIN-rails.

Supply 1 base and top part with sealing, 2 trims, 1 assembly kit incl. cover retention

Close

C6013221

SMART-BOX WIDTH 130
product added to your list
ASA+PC-FR (UL 94 V-0)
light grey RAL 7035
220x130x60mm
IP 66
C6015181 SMART-BOX WIDTH 150

C6015181

SMART-BOX WIDTH 150 Four-part plastic enclosure, ideal for design orientated electrical and electronic applications. The sealing is already prefitted in the top. Screw fixing outside of the sealing area. Recessed operating area to protect the membrane keyboard. Fastening pillars for PCBs and DIN-rails.

Supply 1 base and top part with sealing, 2 trims (hinged), assembly kit incl. cover retention

Close

C6015181

SMART-BOX WIDTH 150
product added to your list
ASA+PC-FR (UL 94 V-0)
light grey RAL 7035
180x150x60mm
IP 66
C6017281 SMART-BOX WIDTH 170

C6017281

SMART-BOX WIDTH 170 Four-part plastic enclosure, ideal for design orientated electrical and electronic applications. The sealing is already prefitted in the top. Screw fixing outside of the sealing area. Resessed operating area to protect the membrane keyboard. Fastening pillars for PCBs and DIN-rails.

Supply 1 base and top part with sealing, 2 trims, 1 assembly kit incl. cover retention

Close

C6017281

SMART-BOX WIDTH 170
product added to your list
ASA+PC-FR (UL 94 V-0)
light grey RAL 7035
280x170x60mm
IP 65
C7008011 IN-BOX

C7008011

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7008011

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
84x82x55mm
IP 66, IP 67, IK 07
C7008012 IN-BOX

C7008012

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7008012

IN-BOX
product added to your list
PC
light grey RAL 7035
84x82x55mm
IP 66, IP 67, IK 08
C7008014 IN-BOX

C7008014

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7008014

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
84x82x55mm
IP 66, IP 67, IK 07
C7008021 IN-BOX

C7008021

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7008021

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
84x82x85mm
IP 66, IP 67, IK 07
C7008024 IN-BOX

C7008024

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7008024

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
84x82x85mm
IP 66, IP 67, IK 07
C7012011 IN-BOX

C7012011

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7012011

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
122x82x55mm
IP 66, IP 67, IK 07
C7012012 IN-BOX

C7012012

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7012012

IN-BOX
product added to your list
PC
light grey RAL 7035
122x82x55mm
IP 66, IP 67, IK 08
C7012014 IN-BOX

C7012014

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7012014

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
122x82x55mm
IP 66, IP 67, IK 07
C7012021 IN-BOX

C7012021

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7012021

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
122x82x85mm
IP 66, IP 67, IK 07
C7012024 IN-BOX

C7012024

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7012024

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
122x82x85mm
IP 66, IP 67, IK 07
C7013031 IN-BOX

C7013031

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7013031

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
124x122x55mm
IP 66, IP 67, IK 07
C7013032 IN-BOX

C7013032

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7013032

IN-BOX
product added to your list
PC
light grey RAL 7035
124x122x55mm
IP 66, IP 67, IK 08
C7013034 IN-BOX

C7013034

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7013034

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
124x122x55mm
IP 66, IP 67, IK 07
C7013051 IN-BOX

C7013051

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7013051

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
124x122x85mm
IP 66, IP 67, IK 07
C7013054 IN-BOX

C7013054

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7013054

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
124x122x85mm
IP 66, IP 67, IK 07
C7016011 IN-BOX

C7016011

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7016011

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
162x82x55mm
IP 66, IP 67, IK 07
C7016012 IN-BOX

C7016012

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7016012

IN-BOX
product added to your list
PC
light grey RAL 7035
162x82x55mm
IP 66, IP 67, IK 08
C7016014 IN-BOX

C7016014

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7016014

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
162x82x55mm
IP 66, IP 67, IK 07
C7016021 IN-BOX

C7016021

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7016021

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
162x82x85mm
IP 66, IP 67, IK 07
C7016024 IN-BOX

C7016024

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7016024

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
162x82x85mm
IP 66, IP 67, IK 07
C7016061 IN-BOX

C7016061

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7016061

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
162x122x90mm
IP 66, IP 67, IK 07
C7016062 IN-BOX

C7016062

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7016062

IN-BOX
product added to your list
PC
light grey RAL 7035
162x122x90mm
IP 66, IP 67, IK 08
C7016064 IN-BOX

C7016064

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7016064

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
162x122x90mm
IP 66, IP 67, IK 07
C7020041 IN-BOX

C7020041

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7020041

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
202x122x75mm
IP 66, IP 67, IK 07
C7020042 IN-BOX

C7020042

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7020042

IN-BOX
product added to your list
PC
light grey RAL 7035
202x122x75mm
IP 66, IP 67, IK 08
C7020044 IN-BOX

C7020044

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7020044

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
transparent
202x122x75mm
IP 66, IP 67, IK 07
C7020061 IN-BOX

C7020061

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7020061

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
202x122x90mm
IP 66, IP 67, IK 07
C7020064 IN-BOX

C7020064

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7020064

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
202x122x90mm
IP 66, IP 67, IK 07
C7021071 IN-BOX

C7021071

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7021071

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
202x152x90mm
IP 66, IP 67, IK 07
C7021072 IN-BOX

C7021072

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7021072

IN-BOX
product added to your list
PC
light grey RAL 7035
202x152x90mm
IP 66, IP 67, IK 08
C7021074 IN-BOX

C7021074

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7021074

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
202x152x90mm
IP 66, IP 67, IK 07
C7025081 IN-BOX

C7025081

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7025081

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
252x162x90mm
IP 66, IP 67, IK 07
C7025082 IN-BOX

C7025082

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7025082

IN-BOX
product added to your list
PC
light grey RAL 7035
252x162x90mm
IP 66, IP 67, IK 08
C7025084 IN-BOX

C7025084

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7025084

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
252x162x90mm
IP 66, IP 67, IK 07
C7025091 IN-BOX

C7025091

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7025091

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
252x162x120mm
IP 66, IP 67, IK 07
C7025094 IN-BOX

C7025094

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7025094

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
252x162x120mm
IP 66, IP 67, IK 07
C7030101 IN-BOX

C7030101

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7030101

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
302x232x90mm
IP 66, IP 67, IK 07
C7030102 IN-BOX

C7030102

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7030102

IN-BOX
product added to your list
PC
light grey RAL 7035
302x232x90mm
IP 66, IP 67, IK 08
C7030104 IN-BOX

C7030104

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7030104

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
302x232x90mm
IP 66, IP 67, IK 07
C7030111 IN-BOX

C7030111

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7030111

IN-BOX
product added to your list
ABS (UL 94 HB)
light grey RAL 7035
302x232x110mm
IP 66, IP 67, IK 07
C7030112 IN-BOX

C7030112

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7030112

IN-BOX
product added to your list
PC
light grey RAL 7035
302x232x110mm
IP 66, IP 67, IK 08
C7030114 IN-BOX

C7030114

IN-BOX Two-piece plastic enclosure with sealing foamed into the top part. Recessed panel to protect membrane keyboards and design foils. Attachment domes for DIN rails, PCBs and mounting plates. Rational stainless steel quick-action lock outside the sealing area.

Supply 1 bottom and top part each with sealing, assembly kit for cover retention and incl. 4 self-tapping screws for installation configuration

Close

C7030114

IN-BOX
product added to your list
ABS/PC (UL 94 HB)
light grey RAL 7035
302x232x110mm
IP 66, IP 67, IK 07
  • Technical Data
  • Purchasing Data
Protection class
Colour
light grey RAL 7035
The degree(s) of protection listed refer to the empty standard enclosures (without any modifications) and are in compliance with the EN 60529 standard.
Please take the dimensions from current parts. These are subject to material- and manufacturing-specific tolerances.
Weight/1 part
4 g
Customs tariff number
(OKW product)
39269097
Country of manufacture
Germany
trafficflow
